Aluminum Fan Blade
The aluminum extrusion profile for fan blade is extensively used in fans, cars, train machinery, electronics, medicine, and other industries. In addition, the aluminum extrusion is often employed as the important auxiliary material in the fields of hardware, machinery, electromechanical parts, solar PV product, to just name a few.
1.The aluminum profile adopts first class material for smooth and subtle edges.
2. It is specially designed with elegant appearance.
3. The surface of the aluminum extrusion profile is colorfully anodized or electrostatic powder coated.
4. Product with customized surface finish is available from us. 5. Our structural aluminum profile offers outstanding engineering design and support.
6. For deep processing, this range of product will be cut, punched, drilled, milled, and then fabricated into finished product.
7. The impeccable quality management system, as well as the strict quality inspection before delivery, is conducive to the excellent performance of the aluminum extrusion profile and the long lifespan up to 15 years.
| Item | Industrial |
| Material | Alloy 6063, 6061, 6060, 6082, or customized |
| Temper | T4, T5, T6, T66 |
| Surface | Anodizing (clear, satin, bronze, black, golden, silver, other multicolor), electrophoretic coating, powder coating, PVDF coating, wood grain painting, etc. |
| MOQ | 1 ton. Usually 12 tons for a 20 feet container, and 24 tons for a 40 feet container. |
| Profile Type | The industrial aluminum profile is generally used in cars, trains, trailers, electronics, medicine, and other industries. |
| Processing | Aluminum profile extruding, precise cutting, straight rectification, bending, drilling, tapping, stamping, pulling, CNC milling, CNC lathe processing. Thanks to precision machining and cutting, the length tolerance and the hole tolerance can be controlled within 0.2mm and 0.05mm, respectively. |
| Molding | 1. Our free mould can be used. 2. The mould can be made according to customers' drawing. |
| Certificate | ISO14001:2004, ISO9001:2000 |
| Standard | Chinese national standard GB/T6892-2006, European standard EN12020-1, 2(2001), and American standard AAMA611-98. |
| FOB Port | Shanghai, etc. |
1.Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
| 6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
| 6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| Alloy | Temper | Tensile Strength | Yield Strength | Elongation |
| 6063 | T5 | ≥160MPa | ≥110MPa | ≥8% |
| T6 | ≥205MPa | ≥180MPa | ≥8% | |
| 6061 | T6 | ≥265MPa | ≥245MPa | ≥8% |
